What are Auxiliary Drains?

Auxiliary Drains (also called Low-Point Drains or Drum Drips) are required for each section of trapped pipe in a Dry or Pre-Action Fire Protection System. They collect the moisture that condensates from the pressurized air in the system while minimizing loss of air pressure during maintenance (see NFPA 13, 8.16.2.5.3.5*, A8.16.2.5.3.5).

Dry and Pre-Action Fire Protection Systems need to be maintained by emptying the auxiliary drains that collect water. Sprinkler system repairs can cost $5,000 to $10,000 or more every time an auxiliary drain fails, is vandalized, or is improperly maintained. AGF Manufacturing's COLLECTanDRAIN® Auxiliary Drains prevent system trips from improper maintenance or vandalism and with regular maintenance, help prevent system breakdowns as a result of freeze-ups.

COLLECTanDRAIN

Auxiliary Drains

Improve your building's appearance and meet NFPA Code

Auxiliary drains become eyesores when they are not maintained properly. Signage falls off, valves break and water stains walls, replacement valves don't match, paint chips, and metal oxidizes. Poorly maintained auxiliary drains make your building look bad, and they lower your occupants trust in the building's infrastructure.

Features Model 5300 A and B pre-assembled auxiliary drains

5300

Material: Galvanized Steel or Black Steel
NFPA 25 Signage:
Water Detector Alarm: Optional
Pre-Assembled:
AGF Model 5200 auxiliary drain with locking plate.

5200

Material: Galvanized Steel or Black Steel
NFPA 25 Signage:
Anti-Trip Plate:
Pre-Assembled:
AGF Model 5100 auxiliary drain with locking plate and water detector alarm.

5100

Material: Galvanized Steel or Black Steel
NFPA 25 Signage:
Water Detector Alarm:
Anti-Trip Plate:
Pre-Assembled:
Material Galvanized Steel or Black Steel Galvanized Steel or Black Steel Galvanized Steel or Black Steel
NFPA 25 Signage
Water Detector Alarm Optional
Anti-Trip Plate
Pre-Assembled
COLLECTanDRAIN

Heated Auxiliary Drain Cabinets

Features COLLECTanDRAIN Model 5400 heated auxiliary drain

5400

Heated Cabinet:
Remote Notification:
NFPA 25 Signage:
Hot Operation Trouble Monitor: Optional

5450

Heated Cabinet:
Sheds Excess Condensation:
Remote Notification:
NFPA 25 Signage:
Hot Operation Trouble Monitor: Optional
AGF COLLECTanDRAIN Model 5500 automatic auxiliary drain

5500

Heated Cabinet:
Automatic Draining:
Remote Notification:
NFPA 25 Signage:
Hot Operation Trouble Monitor:
Heated Cabinet
Automatic Draining
Sheds Excess Condensation
Remote Notification
NFPA 25 Signage
Hot Operation Trouble Monitor Optional Optional
COLLECTanDRAIN

Water Detectors & Accessories

Features

Water Alarm 5100ALBV

Compatible With: All Auxiliary Drains
Collectandrain outdoor cover

Outdoor Cover

Compatible With: 5400, 5450, 5500
AGF COLLECTanDRAIN locking plate

COLLECTanDRAIN Locking Kit

Compatible With: 5100, 5200, 5300

Flood Eliminator 5900FE

Compatible With: 5100, 5200, 5300
Compatible With All Auxiliary Drains 5400
5450
5500
5100
5200
5300
5100
5200
5300
